Item # R&R
Part No. 		OEM
Part No. 		Description Qty
Req
1 R98-0647 98-0647 Hose Assy - RH Drive Motor 1
2 R112-0205 112-0205 Hose Assy - LH Drive Motor 1
3 R237-65 237-65 O-Ring 4
4 R63-4050 63-4050 Fitting - Hyd 2
5 R100-6431 100-6431 Tube - Return 1
6 R237-80 237-80 O-Ring 3
7 R70-7130 70-7130 Line - Tube 1
8 R83-1200 83-1200 Tube - LH Lower Traction 1
9 R150633 95-5986 Hose Assy - Rear Pressure 1
10 R150290 R&R Only Fitting - Hyd 90 Deg 1
11 R92-9767 92-9767 Hose Assy - RH Lift Cylinder 2
12 R63-3850 63-3850 Hose - Cyl LH Drop Fits 1
13 R83-1680 83-1680 Hose - Rear Lift Cyl 1
14 R83-1670 83-1670 Fitting Assy - Special 1
15 R237-21 237-21 O-Ring 7
16 R237-58 237-58 O-Ring - Reel 1
17 R71-0990 71-0990 Orfice 1
18 R237-81 237-81 O-Ring 1
19 R63-4020 63-4020 Tube - Hyd 1
20 R63-4030 63-4030 Tube - Hyd 1
21 R340-77 340-77 Fitting - Hyd 2
22 R237-42 237-42 O-Ring 3
23 R237-22 237-22 O-Ring 5
24 R340-18 340-18 Fitting - Hyd 1
25 R340-16 340-16 Fitting - Hyd 1
26 R83-1890 83-1890 Ball Switch - Control Valve 2
27 R38-0410 38-0410 Nut - Hex - 9/16-18 Thin-SS 2
28 R322-14 322-14 Bolt - Hex Hd 5/16-18 x 3 GR5 3
29 R304-61 304-61 Clamp - Hose 1
30 R445722 32128-20 Nut - Serrated Washer 3
31 R98-2150 98-2150 Hose Assy - Valve to Pump 1
32 R105-3800 105-3800 Control Valve Assy 1
33 R98-2153 98-2153 Hose Assy - RH Drive Motor 1
34 R98-0648 98-0648 Hose Assy - LH Drive Motor 1
35 R150646 R&R Only Seal - Flat 2
36 R2412-41 2412-41 Clamp 2
37 R12-3270 12-3270 Bolt - Hex Washer 1/4-20 x 1/2 1
38 R3256-22 3256-22 Washer - Flat 1/4 Yellow 1
39 R3234-4 3234-4 Bolt - Hex Serrated Washer Hd 1/4-20 x 3/4 1
40 R301504 3296-16 Locknut - ESNA 1/4-20 1
41 R340-138 340-138 Fitting - Hyd 2
42 R237-79 237-79 O-Ring 3
43 R63-3840 63-3840 Hose - Rear Motor Return 1
44 R340-101 340-101 Fitting - Hyd 1
45 R237-79 237-79 O-Ring 2
46 R237-30 237-30 O-Ring - Seal 2
47 R98-0649 98-0649 Hose Assy - Valve to Pump 2
48 R107-9519 107-9519 Hose Assy - Valve to Pump 1
49 R3M41933 3290-379 Cable Ties - 6IN Bulk - Pack/100 2
50 R150296 93-2556 Needle Valve Assy 1
51 R237-22 R&R Only O-Ring 1
51 R150297 R&R Only O-Ring - Needle Valve 1
52 R63-4080 63-4080 Fitting - Valve Manifold - Manual 1
53 R83-1690 83-1690 Hose Assy - Front LH Cylinder 1
54 R88-9700 88-9700 Hose Assy - Rear Lift Cylinder 1
55 R340-103 340-103 Fitting - Hyd 45 Deg 1
55 R340-137 340-137 Use R340-103
56 R83-1350 83-1350 Hose Assy - Steering Cylinder 1
