Item # R&R
Part No. 		  Description Qty
Req
R&R Reels Available, Lifetime Guaranteed
1 R5-3189 Reel - 8 Blade 1
1 R5-3189H Reel - 8 Blade Heavy Duty 1
1 R5-3195 Reel - 9 Blade 1
1 R5-3200 Reel - 4 Blade 1
1 R5-3205 Reel - 5 Blade 1
1 R5-3206 Reel - 6 Blade 1
1 R5-3215 Reel - 5 Blade Heavy Duty 1
1 R12-2789 Reel - 11 Blade 1
1 R12-3599 Use R5-3189
1 R12-8779 Use R5-3205
2 R150480 Brush Reel 1

R&R Bedknives Available, Lifetime Guaranteed
3 R150466 Bedknife - Super Thick 5/16 1
3 R62-2500 Bedknife - Thick 3/16 1
3 R63-8470 Bedknife - Thin 1/8 1
3 R63-8560 Bedknife - Super Thin 3/32 1
3 R65-8250 Bedknife - Tournament 1/16 1
3 R93-4262 Bedknife - Micro Cut

R&R Overhaul Kits Available
9 R13-3659 Overhaul Kit - Cutting Unit
10 R107-1590 Overhaul Kit - Cutting Unit
11 R255-311 Kit - Micro Adjusting
Other Parts Available
12 R150477 Screw - Regular 1/2 Long 13
12 R150476 Screw - Regular 13
13 R253-96 Seal - Oil Single Lip Reel 2
14 R10-5120G Housing - Bearing Reel - Green 1
15 R254-72 Cup - Bearing 2
16 R254-94 Bearing - Tapered Cone 2
17 R32127-46 Locknut - Reel 1
18 R253-61 Seal - Oil Reel 1
19 R10-5080G Roller End - Cap Reel Brg Housing - Green 1
20 R323-2 Bolt - Hex Hd 3/8-16 x 1 1
21 R12-0460 Caplug - End Cap/ Red 1
22 R302-40 Fitting - Grease 1
23 R302-5 Fitting - Grease 6
24 R77-0340 Nut - Splined Reel 1
25 R353-585 Seal - High Pressure 1
26 R3296-39 Locknut - 3/8-16 Nylon 8
27 R150481 Brush Assy - Brush Reel 4
28 R3296-9 Locknut - Comb 12
29 R150426 Washer - 8 SAE 12
30 R150425 Bolt - Hex Hd 8-32 x 5/8 12
31 R150485 Cap - Protective Bearing Housing 1
32 R10-5010 Screw - Roller Adjustment 2
33 R94-2958 Stud - Alloy Ball Joint 2
34 R3254-6 Washer - Lock 3/8 4
35 R321-4 Bolt - Hex Hd 1/4-20 x 3/4 2
36 R3253-3 Washer - Lock 1/4 2
37 R10-5060 Bracket - Roller Adj 2
38 R65-8600 Knob - Height Adjusting 2
39 R441674 Screw - 5/16-18 x 1-3/4 Carriage 2
40 R310266 Washer - Flat 5/16 USS 2
40 R3256-23 Use R310266 2
40 R453009 Washer - Flat 5/16 SAE 2
41 R32153-3 Locknut - 5/16-18 ESNA Zinc 2
42 R70-1200 Frame - Single Point Adj. 1
43 R57-5190 Screw - Adjusting 2
44 R443818 Nut - 1/2-13 Hex Jam Zinc 2
45 R77-0330 Housing - Pivot Spa 1
46 R57-5260 Pivot - 1/2-20 - Bed Bar 1
47 R52-2890 Bushing - Flanged 4
48 R62-5510 Bushing 2
49 R302-18 Zerk - Grease Press Style 1
50 R66-7230 Spring - Single Point Adj 1
51 R257-5 Washer - Thrust 1
52 R77-0350 Retainer - Bearing 2
53 R66-7220 Arm - Spring Handle Assy 1
54 R77-0300 Handle Assy - 1
55 R52-2990 Bolt - Spring Retainer 1
56 R187-0 Washer - Flat 7/16 SAE 1
57 R105-9770 Motor - Reel Hyd Quick Release 1
59 R52-2930 Bolt - Bed Bar 1
60 R63-9510 Bushing - Rubber For Bed Bar 2
61 R52-2860 Washer - Bed Bar Pivot 1
62 R52-2900 Washer - Nylon 2
63 R443828 Nut - 5/8 - 18 Hex 2
64 R52-2910 Bolt - Eccentric Bed Bar 1
65 R57-5200S Shield - Grass - Stainless 1
66 R57-5210 Deflector - Styrene 1
67 R3295-46 Tube - Rivet Smi Grass Shield 13
68 R36-7260 Bar - Cut Off Grass Shield 1
69 R3256-14 Washer - 10 Flat 5
70 R32144-73 Screw - Machine Hex Washer Head 5
71 R57-9910 Bolt - Pivot 2
72 R237-84 Grommet - Rubber 2
73 R354083 Decal - Danger 1
74 R400264 Bolt - Hex Hd 3/8-16 x 1-1/4 2
75 R52-3090 Bracket - LH Rear Roller 1
76 R3290-125 Screw - Set 1/4-20 x 5/16 2
77 R52-3060 Bracket - RH Rear Roller 1
78 R453011 Washer - Flat 3/8 SAE Y/Zinc 4
79 R52-3100 Bolt - Eccentric Shoulder LH 1
80 R52-3110 Bolt - Shoulder Hoc RH 1
81 R285-14 Plug - Pipe Frame 2
82 R322-5 Bolt - Hex Hd 5/16-18 x 1 2
83 R3255-8 Washer - Lock 5/16 Ext 2
84 R32108-20 Screw - Flat Hd Cntrsunk 2
85 R3290-316 Bolt - Hex Tap 3/8-16 x 1-1/2 4
86 R3255-9 Washer - Lock 3/8 Ext. Star 4
87 R321-5 Bolt - Hex Hd 1/4-20 x 7/8 2
88 R3256-22 Washer - Flat 1/4 Yellow 4
89 R301504 Locknut - ESNA 1/4-20 2
